Prct Description
Ultimate Waterproof Military connector, Metal Connector Fischer UP01 UR01
Male cable plug,9pins,natural chrome plated brass shell.
Miniaturization – the trend towards perfection in the smallest design
Key Features
- Rugged
- Compact design with High contact density
- Light weight
- IP68 to -120m / IP69 / Hermetic
- High corrosion resistance
- 5,000 mating cycles
- Tested according MIL
- Excellent data transmission
Prct Technical Quick Details
| RM-U Ultimate Series Short Staright Cable Plug |
| Shell size |
0U, 1U |
Shell model |
Straight plug FGX |
| Gender |
Male, Female |
Contact No. |
2,3,4,5,6,7,8,9,10,12,14,16,19, |
| MOQ |
1pc |
Free Sample |
available |
| Endurance(shell) |
5,000 mating cycles |
IP Level |
IP68 |
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen that is a leading company
in the design, manufacturing and distribution of high-performance connectors and cable assembly solutions.Known for their quality, ruggedness and excellent sealing, our prcts prove to be reliable in the most demanding environments.
Raymo high quality plastic connectors are found that can be widely used in below applications:
Medical, Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application.
Cable to cable connector , RM-U FGX Connector Prcts Photo, Shell size and Dimension
| Technical Characteristics |
| Temperature Range |
- 65° C, +200° C |
Resistance to vibrations |
15 g [10 Hz - 2000 Hz] |
| Shell Material |
Brass with chrome plated |
Humidity |
up to 95% at 60° C/140F |
| Shock Resistance |
100 g [ 6 ms] |
Salt spray corrosion test |
>144hr |
| Climatical Category |
50/175/21 |
Shielding (min) |
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating |
IP68 |
Endurance(shell) |
≥5000 mating cycles |
Our Exhibition
| 2020.11 |
Electronica Munich, Germany |
| 2019 9.24-9.26 |
Testing Expo, Shanghai |
| 2018 11.12-11.15 |
Electronica Munich, Germany |
| 2017 9.11-9.16 |
NAB Show,Netherlands |
| 2016 4.11-4.15 |
HK Fair |
| 2015 10.2-10.7 |
ICEEB, Brasil |
| 2014 10.11-10.15 |
HK Fair |
| 2014 4.11-4.15 |
HK Fair
|
Why Choose US?
- 100% compatible with lemo, , fischer connector
- Help you save at least 50% cost
- All the prcts we got CE, ROHS, SGS,ISO9000 certificate
- Fast delivery: 2-15 working days
- Cable assembly offer, help you save prction time
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
