RAYMO 3B Series Chrome Plated Self Locking Connector

Name: RAYMO 3B Series Chrome Plated Self Locking Connector
Brand: RAYMO
Price: 1 USD

China RAYMO 3B Series Chrome Plated Self Locking Connector factory

Brand Name : RAYMO

Model Number : FGG.3B.332.CLAD82Z

Certification : CE ROHS2.0 REACH SGS ISO9001:2015

Place of Origin : Shenzhen, China

MOQ : 1 pc

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000PCS PER WEEK

Delivery Time : 2-3 working days

Packaging Details : 150pcs/ctn

Prct name : Push pull self locking connector

Model : FGG.3B

Available shell : 00B,0B,1B,2B,3B,4B,5B

Contact no : 2,3,4,5,6,.7,8,9,10,12,14,16,21,26,30,32

Insulator Material : PPS, PEEK

Housing material : Brass with chrome plated

Contact material : Brass with gold plated

Contact Now

RAYMO 3B series 32pin chrome plated Push Pull self locking Connector FGG.3B.332 male cable plug

FGG.3B LEMO Equivalent connector, cable circular push pull connector

RM-FGG-3BC Can be 100% compatible with FGG.3B LEMO CONNECTOR but much cheaper with faster delivery.

Raymo electronics technology ltd is a professional push pull connector manufacturer intergrating connector researching, designing and development,prction and sales !. Raymo offer you various range of push pull circular connectors and cable assembly.You will find raymo connectors in widely range of military denfence, medical, Test and measurement,High Speed Camera,Submarine industry.

Part no details.

Raymo Part No.	Original LEMO Part No.	Item Description
RM-FGG-3BC-332-JS82Z	FGG.3B.332.CLAD82Z	3B series cable plug, multipole 32pin , male contact, 82 cable collet for diameter 7.2-8.2mm cable , nut for a bend relief, natural chrome plated, key G,

Available shell size and contacts

Series	Shell Size	Contacts No. with solder & PCB type
RM-B IP50	00B	2,3,4
	0B	2,3,4,5,6,7,9
	1B	2,3,4,5,6,7,8,10,12,14,16
	2B	2,3,4,5,6,7,8,10,12,14,16,18,19,26
	3B	3,4,6,7,8,10,12,14,16,18,21,30,32

Specifcation

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C/140F
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>144hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating	IP 68	Endurance(shell)	5000 mating cycles

FGG shell dimenions

RAYMO 3B Series Chrome Plated Self Locking Connector

RAYMO Connectors advantages

Cheap price, fast delivery,save your cost.
Free samples.
Easy mating, can be blind-mated guiding mechanism ensures precise alignment.
Increased safety and user friendliness mechanical and color coding prevent misconnection.
Convenient grip even with gloves circular connectors with ribbed housing profile.
Increased equipment life span guiding mechanism optimally protects the contacts.
Robust and shock resistant designs ideal for equipment used in the field.
Long prct durability 5,000 mating cycles guaranteed.

FAQ

Can I order a small list ?, yes, you can, 1 piece is ok.
What quote do you offer? EXW, FOB, CIF and others ways according the your needs.
How transport? Sea Freight, Air Freight and others Express Delivery ways for you.
What is the quality of your prcts guarantee? We have passed ISO9001:2015 Quality Management System Certification, CQM Quality Management System Certification and IQNet Quality Management System Certification, If the quality doesn't accord the standard, you can exchange the goods for free.
Do you have after-sales service? Certainly,you can contact us at any time.

Get a price, lead time, datasheet , NOW !
